Cold Planer

  1. Home
  2. Products
  3. Cold Planer
Cold PlanerTristan Balint2024-10-10T10:27:04-04:00
  • Photos

  • Before & After

  • Video

  • Downloads

  • Photos

  • Before & After

snow on ground before trackless vehicles 5-position folding v-plow attachment on sidewalk tractor snow on ground after trackless vehicles 5-position folding v-plow attachment on sidewalk tractor
  • Video

  • Downloads

Literature
Cold Planer Flyer
Specifications
Cold Planer Specs – English
Cold Planer Specs – French
Manuals
Manual & Parts Book

  • Overview

  • Technical

  • Options

  • Overview

Sidewalk maintenance doesn’t stop when the snow melts. The winter freeze-thaw cycles can cause frost heave and play havoc on pedestrian walkways creating dangerous trip hazards and liability exposure for the city. Removing these hazards is often outsourced to companies that specialize in slab jacking (aka mudjacking), grinding or milling. However, a public works department equipped with a Trackless MT has the ability to repair asphalt and concrete surface damages in a cleaner, faster and more cost-effective manner saving the city from unnecessary costs.

The Trackless Difference

The Trackless MT is available with a 10:1 planetary deep reduction transfer case allowing the tractor to move less than 10 feet per minute when shifted into deep low range. Achieving creeper gear speeds any other way may be cheaper, but Trackless deep reduction will generate 10 times the wheel torque compared to normal low range. This provides smoother, surge-free asphalt or concrete milling with very precise control. Tilt, depth and side shift controls add to the attachments precision and when combined with the articulation of the Trackless MT, give the operator ultimate maneuverability.

Asphalt Drum
Cold Planer Asphalt Drum
Click to enlarge
Concrete Drum
Cold Planer Concrete Drum
Click to enlarge

Your Choice, Asphalt or Concrete

The Asphalt Cold Planer is ideal for repairs to asphalt abutting manhole covers, curb sides, gutters and driveways. It can also be used for pothole repair or any other utility cut.
The Concrete Cold Planer has approximately three times more picks and operates at a higher speed.

Related Attachments
Infrared Asphalt Heater
Line & Stencil Painter
Front End Loader
Pickup Sweeper
Power Angle Sweepers
  • Technical

Specifications
Planing Width 16″ (406mm)
Planing Depth 0 to 6″ (0 to 152mm)
Number of Picks 50 on asphalt drum, 160 on concrete drum
Maneuverability Hydraulic controlled
Tilt: ±19°
Depth: 0 to 6″ (0 to 152mm)
Side shift: 0 to 22″ (0 to 559mm)
Drive Double reduction planetary
Drum Torque Minimum of 25,000 in/lbs @ 2,000 psi
Weights & Dimensions
Model Length Width Height Weight
Cold Planer 69″
1752mm
70″
1778mm
45″
1143mm
1880lbs
852kg

*Measurements are approximate.*
*For detailed tender specifications, contact Trackless Vehicles sales department.*

  • Options


Water Tank & Pump Kit
Click to enlarge
Water Tank & Pump Kit

Add a Spraying System to your Trackless MT to control the dust that can become airborne when using sweepers or cold planer attachments.


Spray Nozzle Kit for Cold Planer
Click to enlarge
Spray Nozzle Kit for Cold Planer

Our asphalt milling attachment can create a cloud of dust. Adding a spray nozzle will keep it under control and help lubricate the millings.
